he information below is from handouts distributed to
attendees of the January 1999 Photonics West conference and the May Laser FX 99
conference. The instruction
manual for the Model 6210 (Revision 0, February 10, 1999) also has the same
specifications as the Photonics West handout, with two exceptions noted below. At the Laser FX 99 conference, Cambridge representatives stressed that these are preliminary specifications and are subject to change. For example, at Laser FX 99 the representatives stated that the Small Angle Step Response Time had been halved to 0.15ms. As of this writing (June 10 1999) these are the most recent available specifications. Please check with Cambridge for any updated information. |
Cambridge Technology Inc.
109 Smith Place, Cambridge, MA 02138
Tel: 617-441-0600
Fax: 617-497-8800
Model 6210 Optical Scanner Preliminary Mechanical and Electrical Specifications
All angles are in mechanical degrees
All specifications apply after a 30 second warm-up
Consult manual for complete operating instructions
Rated Angular Excursion: 40° peak-to-peak
Rotor Inertia: 0.020 gm*cm2, +/- 10%
Torque Constant: 2.5 x 104 dyne-cm/amp, +/-10%
Maximum Coil Temperature: 110°C
Thermal Resistance (Coil to Case): 4°C/Watt, Max
Electrical Specifications/Drive Mechanism
Coil Resistance: 4.1 Ohms, +/- 10%
Coil Inductance: 98 uH, +/- 10%
Back EMF Voltage: 43.6 mV/degree/sec, +/- 10%
RMS Current: 1.6 Amperes at Tcase of 50°C, Max
Peak Current: 6 Amperes, Max
Small Angle Step Response Time: 0.3 ms, with balanced load (but see note above about updated specifications)
Position Detector
Linearity: 99.5%, Minimum, over 40 degrees
Scale Drift: 75 PPM/°C, Maximum
Zero Drift: 25 urad/°C, Maximum
Repeatability, Short Term: 15 microradians
Output Signal, Common Mode: 155 microamperes with AGC current of 30mA, +/- 20%
Output Signal, Differential Mode: 12 microamperes/°, at common mode current of 155 microamperes, +/- 20% (6210 instruction manual states +/-5%)
Cambridge Technology Inc.
109 Smith Place, Cambridge, MA 02138
Tel: 617-441-0600
Fax: 617-497-8800
Model 6200 Optical Scanner Preliminary Mechanical and Electrical Specifications
All angles are in mechanical degrees
All specifications apply after a 30 second warm-up
Consult manual for complete operating instructions
Rated Angular Excursion: 40° peak-to-peak
Rotor Inertia: 0.012 gm*cm2, +/- 10%
Torque Constant: 1.08 x 104 dyne-cm/amp, +/-10%
Maximum Coil Temperature: 110°C
Thermal Resistance (Coil to Case): 7.5°C/Watt, Max
Electrical Specifications/Drive Mechanism
Coil Resistance: 2.4 Ohms, +/- 10%
Coil Inductance: 96 uH, +/- 10%
Back EMF Voltage: 18.9 mV/degree/sec, +/- 10%
RMS Current: 1.6 Amperes at Tcase of 50°C, Max
Peak Current: 6 Amperes, Max
Small Angle Step Response Time: 0.3 ms, with balanced load (but see note above about updated specifications)
Position Detector
Linearity: 99.5%, Minimum, over 40 degrees
Scale Drift: 75 PPM/°C, Maximum
Zero Drift: 25 urad/°C, Maximum
Repeatability, Short Term: 15 microradians
Output Signal, Common Mode: 155 microamperes with AGC current of 30mA, +/- 20%
Output Signal, Differential Mode: 12 microamperes/°, at common mode current of 155
microamperes, +/- 20%
